Servo Driver HAT (B) Servo Drive Board Right Angle Pinheader for Raspberry Pi 16-Channel 12-bit I2C

Servo Driver HAT (B) Servo Drive Board Right Angle Pinheader for Raspberry Pi 16-Channel 12-bit I2C
Waveshare
sku: 1674825
$20.00+10%
$21.99
Shipping from: China
   Description
Features Standard Raspberry Pi 40PIN GPIO extension header supports Raspberry Pi series boards Jetson NanoI2C controlled using only 2 pinsUp to 16 Channel servo PWM outputs 12 bit resolution for each channel 4096 scales Integrates 5V regulator up to 3A output current can be powered from battery through VIN terminalStandard servo interface supports common used servo such as SG90 MG90S MG996R etc Reserved I2C control pins allows to work with other control boardsComes with development resources and manual examples in python like Bluetooth WiFi remote control   Resources User ManualSchematicDemo codeMore info Specifications Power supply 5V Pi connector OR 6V 12V VIN terminal Servo voltage 5VLogic voltage 3 3VDriver PCA9685Control interface I2CDimension 65mm x 30mmMounting hole size 3 0mmSupported Servo This HAT can be used to drive servos such as SG90 ServoMG90S ServoMG996R Servo  Ordering Info This HAT provides 2 options for the onboard pinheader Servo Driver HAT B right angle pinheader make it possible to connect servos even when stacking up  Package Included  Note Raspberry Pi and servos are NOT included   Servo Driver HAT B x1 RPi screws pack 2pcs x1
