STM32F767 Development Board Cortex-M7 Small System Board STM32F767IGT6 STM32

Description Onboard STM32F767IGT6 chipCore Cortex M7 32 bit RISCFeatures Single cycle DSP instructions Operating frequency up to 216MHz Working voltage 1 8V 3 6V Packing LQFP176 Storage resources 1024kB Flash 320kB SRAM Resources 6xSPI 4xUSART 4xUART 3xl2S 1xSAI 3xl2C 1xFMC IxSDIO 2xCAN 1 x USB 2 0 FS HS controller with dedicated DMA 1 x USB HS ULP丨 for external USB HS PHY 1 x 10 100 Ethernet M AC 3xAD 12bit 1us 24 2xDA 12 bit TIM timer 10X general purpose timer 2X advanced timer 2X basic timer 1X low power timer Data access FLASH W25Q128 16MB The basic circuit of on board MCU includes 25MHz 32 768KHz crystal oscillator circuit USB power management circuit and USB interface Except for on board SDRAM and GPIO occupied by SPI FLASH all the pins of the I O peripheral devices are in the form of 2 54mm pin arrays All the resources of the chip can be freely used With JTAG SWD debugging and downloading interface Four ply process stable performance Working frequency up to 180 MHz 225 DMIPS 1 25 DMIPS MHZWorking voltage 1 8V 3 6VSDRAM IS42S16400J 7TLI 8MB Package included 1 x STM32F767 Development BoardPin Descriptions 1 D2 Power indicator2 RESET Reset button3 J6 USB interface4 KEY User button5 25MHz x 32 768MHz crystal6 3 3V regulator device7 Flash W25Q12816MB8 2x27 pin headers in two rows a total of 108 pins GPIO97 power supply and GND119 STM32F767IGT6 chip10 ISP interface 3V3 working voltage positive GND Ope
