SPI Interface RAK2247 SX1301 Based LoRa Gateway Concentrator Module Mini-PCIe RAK833 Upgrade Board

More details Click here to openFrimware Click here to openProduct Background The RAK2247 LoRaWAN Gateway Concentrator Module is a LoRa Concentrator module with mini PCIe form factor based on the SX1301 This enables easy integration into routers and other networking equipment adding LoRaWAN Gateway capabilities The module can be used in any embedded platform offering a mini PCIe slot with an SPI or USB connection Despite its small size this is an 8 channel concentrator module By integrating it together with a computing core a fully fledged LoRaWAN Gateway solution can easily be created Product Features Mini PCIe form factor mounted heat sink SX1301 baseband processor emulates 49 x LoRa demodulators 10 parallel demodulation paths It supports 8 uplinks channels and 1 downlink channel 2 x SX125x Tx Rx front ends high low frequency Built in FT2232H for SPI to USB 2 0 conversion optional Operates at 3 3 V making it compatible with standard 3G LTE card slots of Mini PCI e type Tx power up to 25 dBm Rx sensitivity down to 139 dBm SF12 BW 125 kHz Supports the LoRaWAN 1 0 2 protocol Supports global license free frequency band EU433 CN470 IN865 EU868 US915 AU915 KR920 AS920 and AS923 Supports optionalSPI interface this item orUSB interface Product ID 1646895 LoRa moduleRAK2245 SX1301 baseband processor supports 8 upstream channels 1 downstream channel 2 SX125x high frequency low frequency receiving and transmitting front ends Heat sinkAluminum type heat
