SIM868 GSM GPRS GPS 3 In 1 Module With Antenna For Arduino 51 STM32 Support Voice Short Message TTS DTMF

Product Introduction: SIM868 module is a compatible Quad-Band GSM/GPRS module which combines GNSS technology for satellite navigation. The compact design which integrated GPRS and GPRS/Glonass in a SMT package will significantly save both time and costs for customers to develop GNSS enabled applications. Featuring an industry-standard interface and GNSS function, it allows variable assets to be tracked seamlessly at any location and anytime with signal coverage. General Features: 1.Quad-band 850/900/1800/1900MHz 2.GPRS multi-slot class 12/10 3.GPRS mobile station class B 4.Compliant to GSM phase 2/2+: class 4 (2W, 850/900MHz); class 1 (1W, 1800/1900MHz) 5.Dimensions: 17.6*15.7*2.3mm 6.Control via AT commands (3GPP TS 27.007, 27.005 and SIMCom enhanced AT Commands) 7.Supply Voltage Range: 3.4-4.4V 8.Low power consumption 9.Operating Temperature: -40~85 Celsius Specifications for GPRS Data: 1.GPRS class 12: max. 85.6kbps (downlink/uplink) 2.PBCCH support 3.Coding schemes CS 1, 2, 3, 4 4.PPP-stack 5.USSD Specifications for SMS via GSM/GPRS: 1.Point to point MO and MT 2.SMS cell broadcast 3.Text and PDU mode Software features: 1.0710 MUX protocol 2.Embedded TCP/UDP protocol 3.FTP/HTTP 4.MMS 5.POP3/SMTP 6.DTMF 7.Jammping Detection 8.Audio Record 9.SSL 10.bluetooth 3.0 (optional) Specifications for GNSS: 1.Receiver type 2.33 tracking/99 acquisition channel GNSS receiver 3.Sensitivity: tracking for -165dBm; cold starts for -148 dBm 4.Time-To-First-Fix: cold starts 28s (typ);warm starts 26s; hot starts
