SDM530C Three Phase Remote Control Three Phase Four Wire Din Rail Energy Meter, RS485 Modbus RTU and Pulse Output, CE approved

SDM530C Three Phase Remote Control Three Phase Four Wire Din Rail Energy Meter, RS485 Modbus RTU and Pulse Output, CE approved
thumb
thumb
thumb
thumb
thumb
sku: 32923221133
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$70.00
Shipping from: China
   Technical Details
Accuracy Class: class0.5s
Approval: CE
Brand Name: YISITONG
Communication port: RS485
Dimensions: 125.5*96.5*76.5mm
Display Type: Digital Only
DIY Supplies: Electrical
Max. Current: 100A
Max Operating Current: 80A - 99A
Measurements: kwh, kvarh, kW, kvar,kVA, V, A, PF, Hz, dmd etc.
Measuring Energy Range: 999999.99kwh
Min. Current: 0.5A
Model Number: SDM530C
Output Voltage: 230/400(3~)
Phase: Three Phase
Power Supply: AC
Protocol: Modbus RTU
Pulse output: Passive type
Rated Voltage: 220V
Standard: IEC62053-21
Starting current: 40mA
