RunCam Micro Sparrow WDR 700TVL 2.1mm FOV 16:9 FPV Camera With DVR01 Mini FPV DVR Module

Description: Brand Name: Runcam Item Name: Micro Sparrow 700TVL 2.1mm FPV Camera With DVR01 Module Specifications of Runcam Micro Sparrow 700TVL: Image Sensor: 1/3" CMOS Sensor Horizontal Resolution: 700TVL Lens: 2.1mm (M8) FOV145/16:9 Signal System: NTSC/PAL Switchable on OSD menu Integrated OSD: Yes S/N Ratio >50dB (AGC OFF) Electronic Shutter Speed PAL: 1/25~100,000; NTSC: 1/30~100,000 Auto Gain Control (AGC) : LOW/MIDDLE/HIGH Min. Illumination: 0.01Lux@1.2F WDR: LOW/MIDDLE/HIGH DNR: 2DNR Day/Night: EXT/COLOR/BW/AUTO GEN Power: DC 5-36V Working Current: 12V@70mA / 5V@170mA Dimensions: 19mm*19mm*17mm Net Weight: 4.6g Specifications of DVR01 Module: Power in: DC 3.3-5.5V Work Current: 250mA Max Power out: DC 5V @ Max 250mA Video in: CVBS@1Vp-p 75 Video out: CVBS@1Vp-p 75 Encoder: MJPEG@AVI Resolution: VGA@640 x 480@30(NTSC) 25(PAL) Audio in: MIC Micro SD Card: Max 32G Dimension: 25 x 25mm @20 20 M2 holes Net Weight: 3.5g Features: NTSC/PAL Switchable on OSD menu. Designed for Mini FPV Racing Drone ( 25*25mm @ 20*20mm M2 holes). Lossless video output for VTX (Since it has been loaded to the DVR, it needs to synchronize the video amplification output). Black technology, can record high-frequency vibration motor audio without access to MIC. English Manual for Runcam Micro Sparrow 700TVL, Click Here Package Included: 1 x RunCam Micro Sparrow 1 x Set of screws 1 x 3pin FPV sillcone cable 1 x 5D-OSD menu cable 1 x Runcam DVR01 Mini FPV DVR Module 1 x Set of M2 screws 1 x SD card protector 1 x 3pin FPV silicone cable (Female) 2 x Manual
