Raspberry Pi 3 Model B Quad-Core 1.2 GHz 1 GB RAM

Overview The Raspberry Pi 3 Model B is the third generation Raspberry Pi with a 64-bit 1.2GHz quad-core processor,1GB of RAM, WiFi (b/g/n), and Bluetooth 4.1. Compared with the Raspberry Pi 2 the CPU is running at a 33% faster clock rate (1.2GHz vs 0.9GHz) the more modern core also means a more efficient instruction set, especially when performing operations on 64-bit values. Video and 3D performance has also seen a bump with the VideoCore being clocked at 400MHz for video processing (up from 250MHz) and the 3D graphics processor running at 300MHz (up from 250MHz). In general use you can expect the Raspberry Pi 3 to perform around 50% quicker than the Raspberry Pi 2 running the same software. Features Broadcom BCM2837 64bit ARM Cortex-A53 Quad Core Processor SoC running @ 1.2GHz 1 GB RAM 4 x USB2.0 Ports with up to 1.2A output Expanded 40-pin GPIO Header Video/Audio Out via 4-pole 3.5mm connector, HDMI, CSI camera, or Raw LCD (DSI) Storage: microSD 10/100 Ethernet (RJ45) BCM43143 WiFi on board Bluetooth Low Energy (BLE) on board Low-Level Peripherals: 27 x GPIO UART I2C bus SPI bus with two chip selects +3.3V +5V Ground Power Requirements: 5V @ 2.4 A via microUSB power source Supports Raspbian, Windows 10 IoT Core, OpenELEC, OSMC, Pidora, Arch Linux, RISC OS and More! Connectors Ethernet: 10/100 BaseT Ethernet socket Video Output: HDMI (rev 1.3 & 1.4) ; Composite RCA (PAL and NTSC) Audio Output: Audio Output 3.5mm jack; HDMI; USB 4 x USB 2.0 Connector GPIO Connector: 40-pin 2.54 mm (100 mil) expansion header: 2x20 strip; Providing 27 GPIO pins as well as +3.3 V, +5 V and GND supply lines Camera Connector:15-pin MIPI Camera Serial Interface (CSI-2) Display Connector: Display Serial Interface (DSI) 15 way flat flex cable connector with two data lanes and a clock lane Memory Card Slot: Push/pull Micro SDIO GPIO and layout The GPIO header and layout remains the same as before so all of your existing HATs and add-on boards will work fine with the Raspberry Pi 3. Some cases will not be ideal: the indicator LEDs have moved (to accommodate the Wireless LAN antenna) the microSD slot is no longer spring-loaded meaning a little more access space is required the processor benefits from a little more venting for heat management some of the smaller components on the board have moved it's likely that cases made from metal will cause signal issues with the Wireless LAN and Bluetooth. Device Raspberry_Pi_3 Raspberry_Pi_Zero Raspberry_Pi_1 Raspberry_Pi_2 CPU 1.2GHz quad-core ARM Cortex-A53 CPU from Broadcom 1GHz ARM11 Broadcom CPU 700MHz ARM11 Broadcom CPU 900MHz quad-core ARM Cortex-A7 CPU from Broadcom GPU Videocore IV Videocore IV Videocore IV Videocore IV Memory 1GB 512MB 512MB 1GB Storage microSD card slot microSD card slot SD card slot microSD card slot Connectivity 4 x USB, HDMI, Ethernet, 3.5mm audio jack, Wi-Fi, Bluetooth 1 x microUSB, mini-HDMI, an unpopulated composite video header 4 x USB, HDMI, Ethernet, 3.5mm audio jack 4 x USB, HDMI, Ethernet, 3.5mm audio jack OS Linux, Windows 10 IoT core Linux Linux Linux, Windows 10 IoT core Connectors Camera interface (CSI), GPIO, SPI, I2C, JTAG Unpopulated 40-pin GPIO header, SPI, I2C Camera interface (CSI), GPIO, SPI, I2C, JTAG Camera interface (CSI), GPIO, SPI, I2C, JTAG We provide a series of Raspberry Pi 3 Add-on including GSM add-on V2.0, GPS add-On V2.0, LCD1602 Add-On V2.0, OLED screen customized shield add-On V2.0, 20 pin connector screw prototype add-On V2.0, Raspberry Pi to Arduino connector shield add-On V2.0 2.8 TFT LCD Touch Display Screen Add On V2.0 PiFi DAC: I2S Interface HIFI DAC+ Sound Card For Raspberry PI B+/2B/3 Best Audio Playback Quality
