Raspberry Pi 3 Model B+ (Plus) Mother Board Mainboard With BCM2837B0 Cortex-A53 (ARMv8) 1.4GHz CPU Dual-Band Wireless LAN w/ 1GB RAM

Overview: - The Raspberry Pi 3 Model B+ is the latest product in the Raspberry Pi 3 range, boasting a 64-bit quad core processor running at 1.4GHz, dual-band 2.4GHz and 5GHz wireless LAN, bluetooth 4.2/BLE, faster Ethernet, and PoE capability via a separate PoE HAT. - The dual-band wireless LAN comes with modular compliance certification, allowing the board to be designed into end products with significantly reduced, wireless LAN compliance testing,improving both cost and time to market. - The Raspberry Pi 3 Model B+ maintains the same mechanical footprint as both the Raspberry Pi 2 Model B and the Raspberry Pi 3 Model B. Specifications: - Processor: Broadcom BCM2837B0, Cortex-A53 (ARMv8) 64-bit SoC @ 1.4GHz - Memory: 1GB LPDDR2 SDRAM - Connectivity: 1. 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN, bluetooth 4.2, BLE 2. Gigabit Ethernet over USB 2.0 (maximum throughput 300 Mbps) 3. 4 USB 2.0 ports - Access: Extended 40-pin GPIO header - Video&sound: 1. Full-size HDMI 2. CSI camera port for connecting a Raspberry Pi camera 3. DSI display port for connecting a Raspberry Pi touchscreen display 4. 4-pole stereo output and composite video port - Multimedia: H.264, MPEG-4 decode(1080p30);H.264 encode(1080p30); OpenGL ES 1.1,2.0 graphics - SD card support: Micro SD port for loading your operating system and storing data - Input power: 1. 5V/2.5A DC power input 2. 5V DC via GPIO header 3. Power-over-Ethernet (PoE) support (requires separate PoE HAT) - Environment: Operating temperature, 0-50C More info. can refer to WIKI Package Included: 1x Raspberry Pi 3 Model B+ board
