RF2401 2.4G Wireless Transceiver Module For Remote Control Smart Home

RF2401 2.4G Wireless Transceiver Module For Remote Control Smart Home
Eachine1
sku: 1411506
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$3.15
Shipping from: China
   Description
Item Overview: The RF2401 module is a low-power, high-speed FSK wireless digital communication module designed to operate in the 2.4G ISM global application-free frequency band. In addition to low cost, small size and stable product, the module has a maximum transmit power of 10dBm and a receiving sensitivity of -115dBm, far exceeding the same type of 2.4G wireless module, which can be widely used in daily life and activities. In the case of connection, it meets the requirements of the FCC and ETSI specifications to meet the customer's certification needs. Specifications: Frequency range: 2400-2483.5 MHz Sensitivity up to -115dBm @1.5K Maximum output power: -20~10 dBm Data transfer rate: 1.5-72 kbps Power supply: DC1.9-3.6 V Emission current: 11 mA @-1dBm 36 mA @+10 dB Operating temperature range: -40 ~ +85 C Ultra low current receive mode < 8 mA Ultra low power shutdown mode current < 10nA Weight: 0.5 g Features: - Frequency hopping function - FSK modulation mode - Digital Received Signal Strength Indicator (RSSI) - Low power detection - Integrated voltage regulator Technical Parameters: Parameter Minimum Typical maximum Unit Condition Operating conditions Operating Voltage 2.8 5 6.5 V Operating temperature -40 25 85 Current consumption Emission current 20 mA Emission current 19 mA Sleep current 11 uA RF parameters Frequency Range 2.4 2.484 GHz Serial port baud rate 1200 9600 115200 bps Transmit power -18 3 dBm Application: - remote control - Home automation telemetry - Toy control - Tag reader Package Included: 1 x 2.4G Wireless Transceiver Module
