Item Overview: The RF1212 is a low-cost wireless transceiver module that operates from 300 to 510 MHz and has very low power consumption (3 mA) in receive mode. It integrates a baseband modem with a data transfer rate of up to 150 kb/s. Data processing features include a 64-byte FIFO packet processing that automatically generates CRC and data optimization, while the hardware is highly integrated, allowing for very few external components. The module complies with European (ETSI EN300-220 V2.1.1) and North American FCC (15.247 and 15.249) certification standards. Specifications: Frequency range: 300-510 MHz Sensitivity: up to -110dBm Maximum output power: 12.5dBm Transmitting power: 25mA@+10dBm (emission) Data transfer rate: 0.78-150kbps (@FSK) Power supply: 2.1-3.6V Operating temperature range: -40 ~ +85 C Features: - FSK and OOK modulation modes - Digital Received Signal Strength Indicator (RSSI) - Built-in bit synchronizer input data and clock synchronization and recovery - Frequency hopping function Technical Parameters: Parameter Minimum Typical maximum Unit Condition Operating conditions Operating Voltage 2.1 3.3 3.6 V Operating temperature -40 85 Current consumption Emission current 3 mA Emission current 25 mA @10dBm Sleep current
