RANMEI DIN-Rail Electric Meter 1 phase Energy Meter XTM75S-U KWh Meter 5(30A) 220V

Features: 35mm standard DIN rail installation complying with standard DIN EN50022. Six pole width (Modulus 12.5mm) complying with standard JB/T7121-1993. May select 5+1LCD digits display (99999.1kWh) . Standard configuration port of pulse output passive (polarity) May select increase a distant port of pulse output passive (nonpolarity) complying with standard IEC 62053-31 Standard configuration don t detection direction of the-flow of load current. May select automatic detection the direction of the-flow of load current. And instructions by an individual LED. Single direction measure single phase two wire active energy consumption. It is nothing with direction of the-flow of load current. Complying with standard IEC 62053-21. Standard configuration short terminals cover may select extension terminals cover in order to protect to use safely. Specifications: Model: XTM75S-U Accuracy: Class 1 Voltage: 220V Current: 5(30)A Insulation performance: AC voltage 4kv for 1 minute 1.2/50us waveform impulse voltage 6kv Size: 10 x 7.6cm / 3.94 x 2.99in Weight: Approx. 270-277g Package included: 1 x DIN-Rail Electric Meter 1 x Manual Note: Due to the difference between different monitors the picture may not reflect the actual color of the item. Thank you! Manual measurement please allow 1-10mm error. Thanks for your understanding.
