R307 Optical Fingerprint Reader Module Sensor Finger Detection Function

Features Integrated image collecting and algorithm chip together ALL in OneFingerprint reader can conduct secondary development can be embedded into a variety of end productsUsers can conduct secondary development can be embedded into a variety of end products such as access control attendance safety deposit box car door locksLow power consumption low cost small size excellent performanceProfessional optical technology precise module manufacturing technicsGood image processing capabilities can successfully capture image up to resolution 500 dpiFingerdetection function Specification Type Optical Sensor Life 100 million timesStatic indicators 15KVBacklight BlueInterface USB2 0 UART TTL logical level RS232 communication baud rate 9600BPS 115200BPS changeableImage Capture Surface 1511 mm Verification Speed 0 2 secScanning Speed 0 3 secCharacter file size 256 bytesTemplate size 512 bytesStorage capacity 1000Security level 3 1 2 3 4 5 highest False Acceptance Rate FAR 0 0001 False Rejection Rate FRR 0 1 Resolution 500 DPIVoltage 4 2 6VDC or 3 3V Working current Typical 75mAMatching Method 1 NOperating Envirement Temperature 20 to 50 degreesR307 fingerprint module size chartR307 fingerprint module circuit board diagram3 3VDC power may be selected to supply when short ciucuit as the following drawing Caution Operating carefully and R307 will be damaged when wong connection Package Includes 1 x Fingerprint ReaderYou can down
