R307 Optical Fingerprint Reader Module Sensor Finger Detection Function

Features : Integrated image collecting and algorithm chip together, ALL-in-One Fingerprint reader can conduct secondary development, can be embedded into a variety of end products Users can conduct secondary development, can be embedded into a variety of end products, such as: access control, attendance, safety deposit box, car door locks Low power consumption, low cost, small size, excellent performance Professional optical technology, precise module manufacturing technics Good image processing capabilities, can successfully capture image up to resolution 500 dpi Finger detection function. Specification : Type: Optical Sensor Life: 100 million times Static indicators: 15KV Backlight: Blue Interface: USB2.0/UART(TTL logical level) RS232 communication baud rate: 9600BPS~115200BPS changeable Image Capture Surface 1511(mm) Verification Speed: 0.2 sec Scanning Speed: 0.3 sec Character file size: 256 bytes Template size: 512 bytes Storage capacity: 1000 Security level: 3 (1,2,3,4,5(highest)) False Acceptance Rate (FAR) :0.0001% False Rejection Rate (FRR): 0.1% Resolution 500 DPI Voltage :4.2--6VDC (or 3.3V) Working current: Typical 75mA Matching Method: 1: N Operating Envirement Temperature: -20 to 50 degrees R307 fingerprint module size chart R307 fingerprint module circuit board diagram 3.3VDC power may be selected to supply when short ciucuit as the following drawing. Caution: Operating carefully, and R307 will be damaged when wong connection. Package Includes : 1 x Fingerprint Reader You can download the R307 user manual from this website link: https://www.dropbox.com/sh/epucei8lmoz7xpp/AAAmon04b1DiSOeh1q4nAhzAa?dl=0 Details Pictures :
