QIACHIP RF 315Mhz Receiver & Transmitter Superheterodyne ASK/OOK Wireless Module to MCU Arduino UNO 315 Mhz Remote Control Relay
sku: 32930991145
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$1.74
Shipping from: China
Technical Details
| Application: | Light Switch,Remote Control Switch |
| Brand Name: | QIACHIP |
| Certification: | CE,CCC,RoHS |
| Channel: | 1 |
| Frequency: | 315 MHz |
| Input Voltage of Receiver: | DC 2.2V-5V |
| Input Voltage of Transmitter: | DC 2V-3.6V |
| Launch Distance of Transmitter: | 20-200 meters |
| Model Number: | RF 315Mhz RX500-3 Receiver & WL102-331 Transmitter Wireless Remote |
| Modulation Mode: | ASK/OOK |
| Package: | No |
| Quiescent Current of Receiver: | 1uA |
| Quiescent Current of Transmitter: | 1uA |
| Receiving Sensitivity of Receiver: | -108dBm |
| RF working mode: | Superheterodyne |
| Size of Receiver: | 23.5*9*1 mm |
| Size of Transmitter: | 17*13*1 mm |
| Support APP: | No |
| Transfer Rate of Transmitter: | up to 20KHz |
| Transmit Power of Transmitter: | greater than 11dBm |
| Use: | Universal,Automated curtains,Lighting,Electric Door,Switch |
| Warranty: | 3 months |
| Wireless Communication: | RF |
| Working Current of Receiver: | 2.1mA |
| Working Frequency: | RF 315 Mhz |
| Working Temperature of Receiver: | -40 ~ 85 |
