Precision Digital LCR Meter 100KHz LCR Digital Bridge Inductance Resistance Capacitance Tester East Tester Digital LCR Bridge
Technical Details
| AC Current: | None |
| AC Voltage: | None |
| Basic Accuracy: | 0.2% |
| Brand Name: | BRIGHTWIN |
| Color: | Yellow and black |
| DC Current: | None |
| DCR Mode: | Have |
| DC Voltage: | None |
| Digits Display Mode: | 4 1/2 digit display |
| Dimensions: | 18.5x9.3x4.7cm |
| Display Type: | Digital Display |
| DIY Supplies: | Electrical |
| Electrolytic capacitor mode: | Have |
| Functions: | Digital LCR Bridge meter |
| Internal bias: | 0-500mV adjustable, at a step of 1mV |
| Measuring Capacitance Range: | 0-20mF |
| Measuring Inductance Range: | 0-2000H |
| Measuring Resistance Range: | 0-20M Ohm |
| Model Number: | ET432 |
| Operating Mode: | Button press |
| Operating Power Supply: | Internal Rechargeable Li battery |
| Operating Temperature: | 0 - 40 ℃ |
| Testing frequency: | 100Hz, 120Hz, 1KHz, 10KHz, 40KHz, 100KHz, selectable |
| Testing Level: | 0.1Vrms, 0.3Vrms, 0.6Vrms |
