Portable uSDX 8 Band SDR All Mode Transceiver USB, LSB, CW, AM, FM HF SSB QRP Transceiver QCX-SSB with Battery

Description This is a HF QRP SSB CW transceiver The utra small size is easy to carry to outdoor use using 1602N LCD screen Support to connect to PC and use FT8 JS8 FT4 and other digital mode software control support CW automatic decoding This transceiver kit includes a large number of features defined by the firmware in the ATmega328P microcontroller chip Features Shell size 100 mm x 88mm x 38mm 3 9 3 5 1 5 Interaction and display rotary encoder Menu exit key 1602N LCD Headphone output connector marked Headphone PTT Out interface marked with PTT OUT Mic microphone and key interface and PTT marked mic PTT key Handheld Speaker Microphone PTT combination BaoFeng UV 3R marked SPK MIC The antenna interface is BNC interface with BNC SL16 The power interface is 5 5 2 1 or 5 5 2 5 Specifications Material AluminumPlug US plugWorking voltage 9 13 8V maximum 15V but not recommended and the transmission power will drop below 13 8V Mode support USB LSB CW AM FMDSP filter 4000 2500 1700 500 200 100 50 Hz passbandReceiver noise floor MDS 135dBm at 28MHz in 200Hz BW Blocking dynamic ranges 20kHz offset 123dB 2kHz offset 78 dBPackage size 265 153 90mm 10 4 6 0 3 5inPackage weight 698g 1 5lbPackage Included 1 x Transceiver1 x Microphone1 x DC Adaptor US plug 1 x BNC SL163 x WrenchPlease click here to download the English manual
