Plantower® PMS5003S PM2.5+Formaldehyde Two-in-one Sensor G5S Particulate Formaldehyde Sensor Detector

Feature: This sensor uses the principle of laser light scattering. That is, the laser illuminates the suspended particles in the air to generate scattering, and at the same time, the scattered light is collected at a certain angle to obtain a curve of the scattered light intensity with time. Furthermore, the microprocessor uses an algorithm based on the MIE theory to obtain the equivalent particle size of the particles and the number of particles of different particle sizes per unit volume. Parameter Index Unit Particle measurement range 0.3~1.0, 1.0~2.5, 2.5~10 Micron Particle count efficiency 50%@0.3 micron 98%@>=0.5 micron Weighing volume 0.1 L Formaldehyde range 0-1 MG/m Formaldehyde resolution 0.001 MG/m Maximum error of formaldehyde 2.7@3.3 V Working temperature -10~+50 C Operating humidity range 0-99% Mean time between failures >=3 Y Biggest size 50 x 38 x 21 mm Pin Description: VCC Power +5V GND Power supply- SET Set the pin/TTL level @3.3V high or floating to normal operation, low level to sleep state RXD Serial receiver pin / TTL Level @3.3V TXD Serial transmit pin / TTL level @3.3V RESET Module reset signal / TTL level @3.3V, low reset NC Package includes: 1 x Laser PM2.5 Sensor 1 x Cable
