PYBoard MicroPython Python STM32F405 IoT Development Board

Description: MicroPython development board adopts STM32F405 SCM, sends data by USB port. It works between 3.6V and 10 V, with 4 build in LED light and one accelerating sensor. Let you be a geek by Python easily. It supports Python Language. Functions: 1. On board STM32F405RG MCU 2. 168 MHz Cortex-M4 CPU with 32-bit hardware floating point 3. 1 MB flash storage, 192 KB RAM 4. USB port, serial port, universal memory, HID protocol 5. SD card slot 6. MMA76603 axis accelerator 7. 4 LEDs,one reset button,one universal button 8. 3V 0.3A on board LDO,power by USB or outside battery 9. Real time clock 10. 30 pcs normal IO terminal ,and 28pcs of them support 5V input and output 11. 2 SPI ,2CAN ,2 I2C,5UART ,14PCS 12BIT ADC PIN,2 ADC PIN 12. Board size: 49.4*51.1mm Port specification: U3: SD slot MICRO: USB power supply RST: reset button P1-P8: extended port Package included: 1 x PYBoard MicroPython Python STM32F405 IoT Development Board
