PWM 12V/24V Solar Charge Controller Battery Charging LCD Display Backlight 10A/20A/30A/40A/50A/60A

Description MS series controller is a kind of intelligent multi purpose solar charge and discharge controller The family use the fixed LCD display with a very friendly interface various control parameters can be flexibly set fully meet your various application requirements Features LCD display with backlight 12V 24V DC port for LED light Image of LCD graphic symbol Automatic identification system voltage level Automatic temperature compensation Settable operation mode of load Remote monitoring and control funvtion custom Battery low voltage disconnection LVD Accumulated function of charge and discharge ampere hours 5 0V USB X 2 Total 2 1A Simple button operation Overload short circuit protection Battery reverse discharge protection Battery reverse connection protection Specification ModelMS1024MS2024MS3024MS4024MS5024MS6024Rated current10A20A30A40A50A60ASize150 x 98 x 39mm150 x 98 x 39mm188 x 110 x 47mm185 x 110 x 47mm188 x 135 x 57mm188 x 135 x 57mmInput PanelsMax 180W with battery 12V Max 360W with battery 24V Max 360W with battery 12V Max 720W with battery 24V Max 540W with battery 12V Max 1080W with battery 24V Max 720W with battery 12V Max 1440W with battery 24V Max 900W with battery 12V Max 1800W with battery 24V Max 1080W with battery 12V Max 2160W with battery 24V Rated voltage12 24VInstallation cable area7 AWG 1 6㎜ Open circuit voltage of solar panel17 4V 12V 34 8V 24V Operating temperature 20℃ 60℃Low voltage disconnection LVD 10 7V 21 4VStorage temperatu
