PCI-E X16 to M.2 M-key NVME X4 SSD RAID Array Expansion Adapter Support 2242/2260/2280/22110(PH44Plus)

1. Using high-quality PCB circuit board, gold-plated surface, good conductivity, strong wear resistance, anti-oxidation, high fire rating2. Support 4 X4 full-channel full-speed NVME SSDs and M.2 PCI-E interface devices3. LED soft light indicator light, when the disk is plugged in and powered on, the green light is on, and the green light flashes when reading and writing4. Two-speed turbo fan, heat dissipation on both sides at the same time, more stable transmission5. Equipped with full-height/half-height baffles, which can support the installation of 2U server small chassis6. Compatible with 2242/2260/2280/22110 specifications7. Support M.2 M-KEY NVME protocol SSD and Optane8. Expansion cards and devices supporting M.2 PCI-E protocol9. Support hard disk: M.2 NVME protocol SSD/M.2 PCI-E device10. Transmission speed: 4 x 32Gbps11. Weight: about 92.3 grams12. Packing: cowhide box packingPacking list:-Riser card x 1-Lock plate screw x 4-Mobile stud x 4-Chassis screw x 1-Full height bezel x 1-Half height bezel x 1-Screwdriver x 1
