Owon TAO3102 100MHz 1GS/s Portable Oscillometer 2-CH Digital Storage Oscilloscope 8" LCD Display Handheld Portable Oscil

Features Oscilloscope Multimeter 2CH type 100MHz Bandwidth 1GS s sample rate8 bit high resolution ADC40M record length 45 000 wfms s waveform refresh rateLow back ground noise8 inch 800 x 600 high resolution LCD multi touch screen more user friendly operation experienceSCPI and LabVIEW supportedMulti trigger and bus decoding functionMulti interface integration USB host USB device LANSpecifications ModelTAO3102Bandwidth100MHzSample Rate1GS sVertical Resolution A D 8 bitsRecord length40MWaveform Refresh Rate45 000 wfms sHorizontal Scale s div 1ns div 1000s div step by 1 2 5Channel2Display8 color LCD 800 x 600 pixels display multi touch screenInput Impedance1MΩ ± 2 in parallel with 15pF ± 5pFMax Input Voltage1MΩ ≤ 300Vrms DC Gain Accuracy±3 Probe Attenuation Factor0 001X 1000X step by 1 2 5Sample Rate Relay Time Accuracy±2 5ppmInput CouplingDC AC GNDVertical Sensitivity1mV div 10V div at input Trigger TypeEdge Video Pulse Slope Runt Windows Timeout Nth Edge Logics I2C SPI RS232 and CAN optional Bus Decoding optional I2C SPI RS232 CANTrigger ModeAuto Normal and SingleAutomatic MeasurementVpp Vavg Vrms Freq Period Week RMS Cursor RMS Vmax Vmin Vtop Vbase Vamp Overshoot Phase A→B ↑ Phase A→B↓ Preshoot Rise Time Fall Time Width Width Duty Duty Duty Cycle Delay A→B ↑ Delay A→B↓ Pulse Count Pulse Count Rise Edge Count Fall Edges Count Area Cycle Area Waveform Math ÷ FFT FFTrms Intg Diff S
