Original JYETech DSO062 DIY Digital Oscilloscope Unassembled Kit

Assembly instruction: Click to open Operating instruction: Click to open Feature: Auto / Normal / Single trig modes Rising / Falling edge trigger External trig available Trigger output is available, which makes it possible to cascade scopes to do multi-channel capture. Trigger level adjustable with indicator Hold / run feature Save / recall up to 6 captures FFT function available - size of 256 points and 512 points selectable, sampling rate of 1Ksps to 2Msps selectable Transfer screen to PC as bitmap file via serial connection Built-in 500Hz / 5Vpp test signal Frequency Meter (For TTL level input signal) Auto switching between Oscilloscope Mode and Frequency Meter Mode 9V DC power supply Specification: Maximum equivalent-time sampling rate (repetitive signal): - 20MSa / s Maximum real-time sampling rate: - 2MSa / s Resolution: - 8 bits Record length: - 256 bytes Analog bandwidth: - 1MHz Vertical sensitivity: - 100mV / Div - 5V / Div Vertical position adjustable with indicator Input impedance: - 1M ohm Max input voltage: - 50Vpk (1x probe) [500Vpk for 10x probe] DC / AC / GND coupling Horizontal: - 0.5us / Div - 10m (minute) / Div Dimension: 110mm X 65mm X 25mm (without case) Package included: 1 x DIY Digital Oscilloscope Kit DSO062 DIY Kit Test, for reference only:
