Original Banana Pi G1 Open Debugger Board Burner Module

Original Banana Pi G1 Open Debugger Board Burner Module Introduction: Open Debugger is a set of programming tools in the development of STM series of microcontrollers, TI CC1x, 2x, TI CC3x series SOC, when STC Series MCU can be programmed quickly and easily debug, debugging programmer does not have to do something different series of chips switching plug tedious work. In addition, it also integrates a USB to serial port, which is a common interface for embedded development. It is also one of USB2.0 HUB, making it easy to extend to other USB tools. With it, no longer need to face a bunch of different writer, complicated mess of wiring, USB port deficiencies. Operating Condition: Operating voltage: DC 5V Operating temperature: 0C to 85C The onboard voltage output: 3.3 V Maximum output current: 2000 mA Supported operating systems: Microsoft Windows 2000 Windows XP SP2/SP3 operating system (32-bit versions) Windows Vista operating system (32 and 64 bit) Windows 7 operating system (32 and 64 bit) Windows 8 operating system (32 and 64 bit) Support Objects: a)CC Debugger Interface: Programming and debugging of the following 8051-based TI SoCs: CC1110, CC1111 CC2430, CC2431 CC2510, CC2511 CC2530, CC2531, CC2533 CC2540, CC2541 CC2543, CC2544, CC2545 Control the same apparatus to SmartRF Studio. In addition, you can also control the following transceiver SmartRF: CC1120, CC1121, CC1125, CC1175 CC1100, CC1101, CC110L, CC113L, CC115L CC2500, CC2520 It can also be used to program the PurePath wireless devices: CC8520, CC8521 CC8530, CC8531 b)SWD Interface: Programming and debugging mainstream ARM7 9 11, Cortex-A5 A8 A9 M0 M1 M3 M4 Supported MCU manufacturers: ST, Freecale, Nuvoton, NXP, TI, Cypress, Atmel, Analog, Fujitsu, Toshiba, Energy Micro... Speeds up the programming and debugging functions 4Mhz: Write Flash Rom, EEPROM, ARF, and support for full speed, stepping, breakpoints c)JTAG Interface: JTAG programming and debugging interface for all supported kernel. d)UART Interface: STC series microcontroller programming and debugging output port for printing information. Package included: 1 x Original Banana Pi G1 Open Debugger Acronym table CSn Chip Select (active low) DC Debug Clock DD Debug Data RST Debug Reset DUT Device Under Test GND Ground LED Light Emitting Diode MISO Master In Slave Out MOSI Master Out Slave In RF Radio Frequency SCLK Serial Clock SoC System-on-Chip SPI Serial Peripheral Interface USB Universal Serial Bus Target Positive voltage on target CLK SWD Clock DIO SWD DATA Input/Output TMS JTAG Test Mode Select TCK JTAG Test Clock Input TDO JTAG Test Data Output TDI JTAG Test Data Input SRST JTAG Test Reset Input, Active Low RXD USB Serial Input TXD USB Serial Output
