Original Banana PI BPI-M1 Dual Core A20 1GB RAM WiFi Module

Hardware:Soc: Allwinner A20 CPU: ARM Cortex-A7 Dual-Core 1 GHz (ARM v7 instruction set) GPU: Mali400MP2 Complies with OpenGL ES 2.0/1.1 (hardware acceleration support) SDRAM: 1GB DDR3(shared with GPU) Power: 5V/2A via MicroUSB (DC in Only) and /or Micro USB (OTG) PMU: AXP209Features: Low-level perpherials 40 Pins Header, 28xGPIO, some of which can be used for specific functions including UART, I2C, SPI, PWM, CAN, I2S, SPDIF, LRADC, ADC, LINE-IN, FM-IN, HP-IN On board Network 10/100/1000Mbps ethemet(Realtek RTL8211E/D) Wifi Module Wifi 802.11 b/g/n Bluetooth Optional On board Storage Micro SD(TF) Card,SATA 2.0 Display HDMI 1.4 (Type A -full) LVDS/RGB/CPU display interface (DSI) for raw LCD panels Composite Video (PAL and NTSC) (via 3.5mm TRRS jack shared with audio out) 11 HDMI resolutions from 640x480 to 1920x1080 plus various PAL and NTSC standards Video HD H.264 2160p video decording Multi-format FHD video decording,including Mpeg 1/2 ,Mpeg4,H.263,H.264,ect H.264 high profile 1080p@30fps or 720p@60fps encording Audio outputs HDMI ,analog audio(via 3.5mm TRRS jack shared with composite video out),I2S audio (also potentially for audio input) Camera Parellel 8-bit camere interface Audio input On board microphone USB 2USB 2.0 host,1 USB 2.0 OTG (all direct from A20 chip) Buttons Reset button, Power button, U-boot button Leds Power status led(red), User defined led1(green), User defined led2(blue) Other IR receiver Size 92 x 60mm Weight 45g Package included:1x Banana Pi M1
