Original BPI-R1 Intelligent Router SATA Interface For Banana Pi

Original BPI-R1 Intelligent Router SATA Interface For Banana Pi Introduce: The BPI- R1 is a 300Mbps Wireless N Router with both wired and wireless network connections designed specifically for smart home networking use. With 2T2R MIMO Technology and two detachable antennas, the R1 is the dual core Android 4.2 product which more better than Linux product. It can run with Android V4.2.2 smoothly and with Gigabit ethernet port, SATA Socket, it can easily run with the game and support 1080P high definition video output Specification: CPU A20 ARM Cortex-A7 Dual-Core GPU ARM Mali400MP2 Complies with OpenGL ES 2.0/1.1 Memory (SDRAM) 1GB DDR3 (shared with GPU) Onboard Storage Micro SD (Max. 64GB) card slot, UP to 2T on 2.5 SATA disk Onboard Network 10/100/1000 Ethernet RJ45, WLAN @802.11b/g/n Video Input A CSI input connector allows for the connection of a designed camera module Video Output HDMI, LVDS / RGB Audio Output 3.5 mm Jack and HDMI Audio Input Microphone Power Source 5 volt via Micro USB (DC In Only) USB 2.0 Ports USB Host and Micro USB (OTG) Buttons Reset button Next to Power button Power button Next to Battery connector GPIO(2X13) pin GPIO, UART, I2C bus, SPI bus with two chip selects, CAN bus, ADC, PWM, +3.3V, +5V, ground LED Power Key & RJ45 Remote IR OS Android 4.2, Linux Product size 148 100mm Weight 83g GPIO Define: We can check R1 PIN definition in this thread, including CON1, CON2, CON3,J12 and J13. J13 contains the default serial port UART0 (UART0-RX,UART0-TX). UATR0 is configured to be used for console input/output. Whilst this is useful if you want to login using the serial port. So it is the most common used PIN. J12 also contains serial port. CON3 contains CAN bus, SPI bus, PWM, serial port and etc. It can be configured to be used for kinds of peripherals. CON1 is a CSI camera connector. CON2 is a DSI display connector. Pictures and tables below show the specific layout and definition of PIN. Package included: 1 x BPI-R1 Intelligent Router
