Open Source Maker NanoPi NEO all-in-one H3 Development Board Running UbuntuCore

Introduction The NanoPi NEO abbreviated as NEO is another fun board developed by FriendlyARM for makers hobbyists and fans Hardware Specification CPU Allwinner H3 Quad core Cortex A7 Up to 1 2GHzDDR3 RAM 256MB 512MB Optional Connectivity 10 100M EthernetUSB Host Type A x 1 2 54 mm pin x 2MicroSD Slot x 1MicroUSB OTG for power inputDebug Serial Port 4Pin 2 54 mm pitch pin headerAudio input output Port 5Pin 2 0mm pitch pin headerGPIO 2 54mm pitch 36pin It includes UART SPI I2C IO etcPower Supply DC 5V 2APCB Dimension 40 x 40 mmWorking Temperature 40℃ to 80℃Weight 14g WITHOUT Pin headers OS Software u boot UbuntuCore and AndroidMore informations http wiki friendlyarm com wiki index php NanoPi NEOSource code https github com friendlyarmGPIO Pin Description Pin NameLinux gpioPin NameLinux gpio1SYS 3 3V2VDD 5V3I2C0 SDA4VDD 5V5I2C0 SCL6GND7GPIOG112038UART1 TX GPIOG61989GND10UART1 RX GPIOG719911UART2 TX GPIOA0012GPIOA6613UART2 RTS GPIOA2214GND15UART2 CTS GPIOA3316UART1 RTS GPIOG820017SYS 3 3V18UART1 CTS GPIOG920119SPI0 MOSI GPIOC06420GND21SPI0 MISO GPIOC16522UART2 RX GPIOA1123SPI0 CLK GPIOC26624SPI0 CS GPIOC367Package includes 1 xNanoPi NEO
