Open Source Maker NanoPi NEO all-in-one H3 Development Board Running UbuntuCore For Arduino

Introduction: The NanoPi NEO(abbreviated as NEO) is another fun board developed by FriendlyARM for makers, hobbyists and fans. Hardware Specification: CPU: Allwinner H3, Quad-core Cortex-A7 Up to 1.2GHz DDR3 RAM: 256MB/512MB (Optional) Connectivity: 10/100M Ethernet USB Host: Type-A x 1, 2.54 mm pin x 2 MicroSD Slot x 1 MicroUSB: OTG, for power input Debug Serial Port: 4Pin, 2.54 mm pitch pin header Audio input/output Port: 5Pin, 2.0mm pitch pin header GPIO: 2.54mm pitch 36pin. It includes UART, SPI, I2C, IO etc Power Supply: DC 5V/2A PCB Dimension: 40 x 40 mm Working Temperature: -40 to 80 Weight: 14g(WITHOUT Pin-headers) OS/Software: u-boot, UbuntuCore and Android More informations: http://wiki.friendlyarm.com/wiki/index.php/NanoPi_NEO Source code: https://github.com/friendlyarm GPIO Pin Description: Pin# Name Linux gpio Pin# Name Linux gpio 1 SYS_3.3V 2 VDD_5V 3 I2C0_SDA 4 VDD_5V 5 I2C0_SCL 6 GND 7 GPIOG11 203 8 UART1_TX/GPIOG6 198 9 GND 10 UART1_RX/GPIOG7 199 11 UART2_TX/GPIOA0 0 12 GPIOA6 6 13 UART2_RTS/GPIOA2 2 14 GND 15 UART2_CTS/GPIOA3 3 16 UART1_RTS/GPIOG8 200 17 SYS_3.3V 18 UART1_CTS/GPIOG9 201 19 SPI0_MOSI/GPIOC0 64 20 GND 21 SPI0_MISO/GPIOC1 65 22 UART2_RX/GPIOA1 1 23 SPI0_CLK/GPIOC2 66 24 SPI0_CS/GPIOC3 67 Package includes: 1 x NanoPi NEO
