One-way Relay Module Trigger Delay Loop Timing Circuit Switch Electrical Equipment Supplies Relays

Description: Material: ABS + electronic components Working voltage: 6--30 V power supply Trigger signal source: high level touch (3.0V~24V) low level trigger (0.0V~0.2V) switching quantity control (passive switch). 3: Output capacity: can control devices within 30v 10A or within 220v5A Quiescent current: 15 mA Working current: 50 mA Service life: more than 100,000 times Working temperature: -40-85 C Weight: 45 g Size: 7.1*3.9*2.5 cm (length, width and height) Principle: time relay Protective features: sealed Liaison load: low power Power mode: DC Features: 1. With liquid crystal display, the current mode and parameters are clear at a glance, very clear, simple and practical; 2. Support button trigger control, high and low level trigger, switch quantity control, suitable for most occasions; 3. Wide voltage supply (6~30V) very convenient to use; 4. Support UART data upload and parameter setting; 5. One-button pause function with reverse connection protection, reverse connection does not burn; 6. Added sleep mode. After enabling, there is no operation for about 5 minutes, and the LCD backlight is automatically turned off; any button wakes up; 7. Different OP, CL, LOP parameters can be set. These parameters are independent of each other and saved separately. 8. All setting parameters are automatically saved after power off. Product parameters: 9. With optocoupler isolation, enhance anti-interference ability, industrial grade circuit board, set parameters to remember forever after power off. Scope of application: small appliance control, MCU development and so on. Package included: 1 x One-way Relay Module Trigger Delay Loop Timing Circuit Switch
