OWON XSA805 9kHz-500MHz 9Inch TFT LCD Display Spectrum Analyzer Support USB LAN HDMI Communication Interface

Features Model XSA805Frequency range 9kHz 500MHz 160 dBm Displayed Average Noise Level DANL Phase noise 80 dBc Hz lGHz and offset at 10 kHzTotal amplitude accuracy 0 7 dB1 Hz minimum resolution bandwidth RBW EMI pre compliance test kit optional EMC test softwareWaterfall plot graphic modulation signal quality analysis audio demodulation ect multiple general and extended test functions Standard Pass Fail on site test and alert functionAdopt all digital intermediate frequency technologyMultiple interfaces USB Host USB Device LAN earphone interface HDMI9 inch LCD high resolution 1280X800 pixelsSpecification Model No XSA805XSA810XSA815FrequencyFrequency Range9kHz 500MHz9kHz 1GHz9kHz 1 5GHzFrequency Resolution1HzFrequency Span Range0 Hz 100 Hz to the max frequency rangeAging Rate1 ppm yearFrequency Counter Resolution1Hz 10 Hz 100 Hz 1 kHzResolution Bandwidth 3 dB 1Hzto 1MHz 1 10 step 1 MHz 3MHzVideo Bandwidth 3 dB 1Hzto 1MHzPhase Noise 20 ℃ to 30 ℃ c 1 GHz 80 dBc Hz 10 kHz offsetPhase noise 100dBc Hz 100 kHz offset 115dBc Hz 1 MHz 500MHz offsetLevel UnitdBm dBuW dBpW dBmV dBuV W VTrace Detectorspositive peak negative peak sample normal RMS average quasi peakTrace Functionsclear write max hold min hold view blank average trace mathVSWR300 kHz to 1 5 GHz when input10 dBnominal when input1 5dBGeneralDisplay9 1280x800 pixels TFT LCDCommunication InterfaceUSB host USB device LAN earphone port HDMI Package Included 1 x
