OWON VDS1022I Virtual PC USB Oscilloscope 100MSa/S 25M Dual-Channel Oscilloscopes with Probe Cable Tools Accessory

Features Up to 100MHz bandwidth and max 1GS s real time sample rate2 4 channelsMax 10M record lengthFriendly UI FFT or X Y and waveform 2 views displayed on the same screenMulti trigger option edge video slope pulse and alternateUSB isolation less interference more PC protectionUSB bus powering and LAN remote control optional Ultra thin body design easy portabilitySCPI supportedSpecification ModelVDS1022IBandwidth25MHZChannel2 1 multi Sample Rate100MSa sHorizontal Scale s div 5ns div 100s div step by i 2 5Rise Time14 nsRecord Length5KInput CouplingDC AC GNDInput Impedance1MΩ±2 in parallel with 10pF±5pFChannels Isolation50Hz 100 1 10MHz 40 1Max Input Voltage400V PK PK DC AC PK PK DC Gain Accuracy±3 DC AccuracyAverage≥16 士 3 reading 0 05div forTriangle TProbe AttenuationFactorIX 10X 100X 1000XLF Respond AC 3dB 5Hz at input AC coupling 3dB Sampling Rate Relay Time Accuracy150psInterpolationsin x xInterval Triangle T Accuracy fullbandwidth Single 土 1 interval time 100ppm xreading 0 6ns Average 16 ± 1 intervaltime 100ppm x reading 0 4ns Vertical Resolution A D 8 bits 2 channels simultaneously Vertical Sensitivity5mV div 5V divTrigger TypeEdge Pulse Video Slope AlternateTrigger ModeAuto Normal SingleTrigger Level±5 divisions from screen centerAcquisition ModeSample Peak Detect and AverageLine FieldFrequency video NTSC PAL and SECAM standardCursor MeasurementTriangle V and Triangle T between cursorsAut
