OSC482X Digital Portable Oscilloscope OSC482X PC USB 2.0 Virtual 2CH Bandwidth Oscilloscope with 13M Hz Signal Generator + 4 Channels Logic Analyzer

OSC482X Digital Portable Oscilloscope OSC482X PC USB 2.0 Virtual 2CH Bandwidth Oscilloscope with 13M Hz Signal Generator + 4 Channels Logic Analyzer
oscilloscope
sku: 1537504
$87.50-4%
$84.00
Shipping from: China
   Description
Features: Small size for easy carrying, 153 (long) x 93 (wide) x 23 (height) mm. Suitable for laptops, Android phones, production line maintenance adjustments, easy to use for business trips More than 20 automatic measurement functions FFT spectrum analysis Provide GPIO interface Provide software interface protocol for secondary development of customers. The USB 2.0 interface draws power directly from the host without the need for additional power The oscilloscope and data logger PC PC phone software is completely free. Achieve PC large screen display and PC desktop oscilloscope similar interface, easy to get started Support multiple serial protocol decoding. Support for Android phones TTL level with 13MHZ signal generator function + 4 channel logic analyzer function Software supports Windows XP, Win 7, Win 8.1, Win10 (32 bit and 64 bit) and Android phone/tablet. Voice Chinese English can be switched APPLICATIONS: General and precision testing. Embedded in teaching equipment or industrial test systems. Power ripple and noise detection. Multi-sensor system and serial bus decoding. Analog data acquisition and secondary development applications for digital IO control projects. Analysis of voltage/current data records for solar systems and lighting systems. On-site maintenance engineer's troubleshooting tool. DIY enthusiasts and basic tools for makers. Software download link: http://bbs.lotoins.com/support.html Software User's Manual: Click to view the software manual Specification: Model: OSC482 OSC482M OSC482S OSC482L OSC482X OSC482F Detail: Support Windows XP, Win 7, Win 8.1, Win10 (32 bit and 64 bit). OSC482 + 13M Hz Signal generator. OSC482 + 4 channels Logic analyzer. OSC482+13M Hz Signal generator + 4 channels Logic analyzer. OSC482M + 13M Hz Signal generator + 4 channels Logic analyzer. Support Windows XP, Win 7, Win 8.1, Win10 (32 bit and 64 bit) and Android phone/tablet. Input channels: 2 2 2 2 2 2 Maximum sampling rate : 50M S/s 50M S/s 50M S/s 50M S/s 50M S/s 50M S/s Bandwidth: 20M Hz 20M Hz 20M Hz 20M Hz 20M Hz 20M Hz FFT: Data logger: I/O extension: Decode: Signal generator module support: X X X Logic analyzer module support: X X X Net weight: 198 g. Input sensitivity (10 vertical divisions): 20 mV/div to 2 V/div. Input ranges( probe x1): 100 mV to 5 V full scale, in 7 ranges. Timebase selection (10 horizontal divisions): 50 ns/div ~ 2 s/div, in 19 ranges. Typical noise (peak to peak voltage): 20 mv/div 2 mv 50 mv/div 3.4 mv 100 mv/div 6.4 mv 200 mv/div 21 mv 500 mv/div 32 mv Connector type : 2 channels with BNC sockets, 20 mm spacing. Vertical resolution: 8 Bit. Maximum sampling rate (S/s): 50M Bandwidth ( 3 dB): 20MHz Input coupling: AC/DC. Input characteristics: 1M || 25pF. PC OS requirements: Windows XP, Win 7, Win 8.1, Win10 (32 bit and 64 bit). Overvoltage protection: 60.0v (x1) 600.0v (x10). (DC + AC peak) Triggering type: Rising/falling edge according to trigger level. Triggering mode: None, auto, normal, single. pre-trigger capture: 50% of capture size. Automatic measurements: Maximum, minimum, average, RMS, frequency, period, positive pulse width, negative pulse width, duty cycle, rise time, peak-to-peak value, Deep measurement. Samples Interpolation: Linear or sin(x)/x. FFT: 1024 ~ 16k points. FFT window function: Rectangle, Hanning, Hamming, Blackman. Math: A+B, A-B, AxB, X-Y. Acquisition Modes: Normal mode / High Resolution mode / Peak detect mode. Waveform recording File format : *.oscxxx. and playback: Record depth: 50 ~ 450 frames. File size: 6 MB ~ 20GB. Data logger Sampling Interval: 1 second to 1 hour. Data logger Record Duration: 1 minute ~ 72 hours. Temperature range: Operating: 0 C to 40 C (20 C to 30 C for stated accuracy). Storage: 20 C to +60 C. Reference Output: 1K Hz, 1.5 V square wave output with 50% duty cycle. Size: 153(L) x 93(W) x 23(H) mm. Languages (full support): English, Chinese (simplified). Compliance: CE, FCC. Click here for more detailed parameters and how to use the product. Package included: 1 x Digital Hand-held Oscilloscope 2 x High Voltage Probe 1 x USB Cable 1 x Compensation Adjusting Rod 8 x Identification Ring 2 x Tip Locating Sleeve 1 x 13M Hz Signal Generator 1 x 4 Channels Logic Analyzer Related Links: OSC482F:https://www.banggood.com/Digital-Portable-Oscilloscope-OSC482F-PC-Android-USB-2_0-Virtual-2CH-Bandwidth-Oscilloscope-with-13M-Hz-Signal-Generator-4-Channels-Logic-Analyzer-p-1537506.html OSC482M:https://www.banggood.com/Digital-Portable-Oscilloscope-OSC482M-PC-Android-USB-2_0-Virtual-2CH-Bandwidth-Oscilloscope-p-1537507.html OSC482L:https://www.banggood.com/Digital-Portable-Oscilloscope-OSC482L-PC-USB-2_0-Virtual-2CH-Bandwidth-Oscilloscope-with-4-Channels-Logic-Analyzer-p-1537508.html OSC482X:https://www.banggood.com/Digital-Portable-Oscilloscope-OSC482X-PC-USB-2_0-Virtual-2CH-Bandwidth-Oscilloscope-with-13M-Hz-Signal-Generator-4-Channels-Logic-Analyzer-p-1537504.html OSC482S:https://www.banggood.com/Digital-Portable-Oscilloscope-OSC482S-PC-USB-2_0-Virtual-2CH-Bandwidth-Oscilloscope-with-13M-Hz-Signal-Generator-p-1537505.html Signal Generator(Upgrade accessories):https://www.banggood.com/OSC482-Series1-Hz-13MHz-48M-Single-Channel-Output-Series-Function-Upgrade-Module-S02-Signal-Generator-Single-Channel-Output-Virtual-Oscilloscope-p-1539219.html Logic Analyzer(Upgrade accessories):https://www.banggood.com/OSC482-Series-Function-Upgrade-Module-L01-Logic-Analyzer-Module-4-Channels-TTL-Level-Consistent-with-The-Performance-of-Host-Equipment-p-1539220.html OSC802:https://www.banggood.com/Virtual-Oscilloscope-USB-PC-Oscilloscope-OSC802-80M-Sampling-25M-Bandwidth-Dual-Channel-p-1541214.html OSC2002L(OSC2002+Logic Analyzer):https://www.banggood.com/OSC2002LOSC2002Logic-Analyzer-PC-Virtual-Digital-Handheld-Oscilloscope-2-Channel-Bandwidth-50Mhz-Sampling-Data-1G-with-Probe-USB-Cable-p-1538568.html OSCA02:https://www.banggood.com/OSCA02-35MHz-2-CH-Oscilloscope-100Ms-Sampling-Rate-Hand-held-Portable-USB-PC-Virtual-Digital-Oscilloscope-p-1540677.html OSCA02L(OSCA02+Logic Analyzer):https://www.banggood.com/OSCA02LOSCA02Logic-Analyzer-35MHz-2-CH-Oscilloscope-100Ms-Sampling-Rate-Hand-held-Portable-USB-PC-Virtual-Digital-Oscilloscope-p-1541238.html OSCA02:https://www.banggood.com/OSCA02-35MHz-2-CH-Oscilloscope-100Ms-Sampling-Rate-Hand-held-Portable-USB-PC-Virtual-Digital-Oscilloscope-p-1540677.html OSCA02L(OSCA02+Logic Analyzer):https://www.banggood.com/OSCA02LOSCA02Logic-Analyzer-35MHz-2-CH-Oscilloscope-100Ms-Sampling-Rate-Hand-held-Portable-USB-PC-Virtual-Digital-Oscilloscope-p-1541238.html Details pictures:
