OSC2002 PC Virtual Digital Handheld Oscilloscope 2 Channel Bandwidth 50Mhz Sampling Data 1G with Probe USB cable

Specifications ModelOSC2002Connector type 2 channels with BNC sockets 20 mm spacing Vertical resolution 8 Bit Maximum sampling rate S s 1 GBandwidth 3 dB 50 MHzInput coupling AC DC Input characteristics 1MΩ 25pF PC OS requirements Windows XP Win 7 Win 8 1 Win10 32 bit and 64 bit Over voltage protection 60 0v x1 600 0v x10 DC AC peak Triggering type Rising falling edge according to trigger level Triggering mode None auto normal single Pre trigger capture 50 of capture size Automatic measurements Maximum minimum average RMS frequency period positive pulse width negative pulse width duty cycle rise time peak to peak value Samples Interpolation Linear or sin x x FFT 1024 points FFT window function Rectangle Hanning Hamming Blackman Math A B A B AxB X Y Acquisition Modes High Resolution mode Peak detect mode Waveform recording and playback File format oscxxx Record depth 50 450 frames File size 6 MB 20GB Data logger Sampling Interval 1 second to 1 hour Data logger Record Duration 1 minute 72 hours Temperature range Operating 0 C to 40 C 20 C to 30 C for stated accuracy Storage 20 C to 60 C Reference Output 1K Hz 1 5 V square wave output with 50 duty cycle Size 153 L x 93 W x 23 H mm Languages full support English Chinese simplified Compliance CE FCC ModelOSC2002Net weight 210 g Input sensitivity 10 vertical divisions 50 mV div to 2 V div Input ranges probe x1 250 mV to 5 V full scale in 6 ranges Timebas
