OSC2002 PC Virtual Digital Handheld Oscilloscope 2 Channel Bandwidth 50Mhz Sampling Data 1G with Probe USB cable

Specifications: Model OSC2002 Connector type : 2 channels with BNC sockets, 20 mm spacing. Vertical resolution: 8 Bit. Maximum sampling rate (S/s): 1 G Bandwidth ( 3 dB): 50 MHz Input coupling: AC/DC. Input characteristics: 1M || 25pF. PC OS requirements: Windows XP, Win 7, Win 8.1, Win10 (32 bit and 64 bit). Over voltage protection: 60.0v (x1) 600.0v (x10). (DC + AC peak) Triggering type: Rising/falling edge according to trigger level. Triggering mode: None, auto, normal, single. Pre-trigger capture: 50% of capture size. Automatic measurements: Maximum, minimum, average, RMS, frequency, period, positive pulse width, negative pulse width, duty cycle, rise time, peak-to-peak value. Samples Interpolation: Linear or sin(x)/x. FFT: 1024 points. FFT window function: Rectangle, Hanning, Hamming, Blackman. Math: A+B, A-B, AxB, X-Y. Acquisition Modes: High Resolution mode / Peak-detect mode. Waveform recording and playback: File format : *.oscxxx. Record depth: 50 ~ 450 frames. File size: 6 MB ~ 20GB. Data logger Sampling Interval: 1 second to 1 hour. Data logger Record Duration: 1 minute ~ 72 hours. Temperature range: Operating: 0 C to 40 C (20 C to 30 C for stated accuracy). Storage: 20 C to +60 C. Reference Output: 1K Hz, 1.5 V square wave output with 50% duty cycle. Size: 153(L) x 93(W) x 23(H) mm. Languages (full support): English, Chinese (simplified). Compliance: CE, FCC. Model OSC2002 Net weight: 210 g. Input sensitivity (10 vertical divisions): 50 mV/div to 2 V/div. Input ranges (probe x1): 250 mV to 5 V full scale, in 6 ranges. Timebase selection (10 horizontal divisions): 5 ns/div ~ 2 s/div, in 21 ranges. Typical noise (peak to peak voltage): 20 mv/div / 50 mv/div 5.8 mv 100 mv/div 8 mv 200 mv/div 22 mv 500 mv/div 38.8 mv 1 v/div 88.2 mv GPIO: 3 I/O Memory depth ((byte /ch): 64K 100 ms/div 258k 200 ms/div 645k 500 ms/div 1M 1s/div 2M 2ms/div Trigger type: Hardware Trigger source: Channel A Power consumption: 5 v || (248~279) mA Protocols decoding: UART/RS-232, IC OSC_2002 Software download: Package includes: 1 x Oscilloscope 1 x One Set of Accessories Details pictures:
