Non-Contact Phase Sequence Detector Phase Detector Directly Detect Dynamic Sound And Light Indicates For Phase Sequence Detection Live Line Check

Non-Contact Phase Sequence Detector Phase Detector Directly Detect Dynamic Sound And Light Indicates for Phase Sequence Detection Live Line Check Specification: Feature: Phase sequence detection live line check simple power check live wire identification phase loss judgment wire break position search DC line break point detection line maintenance. Clamp-type non-contact inductive measurement no need to open the wire no need to touch the high-voltage exposed fire wire directly sandwich the three super-inductive high-insulation clamps to the insulation skin of the three-phase live wire to detect the phase sequence. Non-contact inspection for safe and fast productivity. The dynamic sound and light indicates the positive or negative phase of the phase sequence of the three-phase power supply which is clear at a glance. The bottom plate of the instrument is equipped with 4 magnets which can be attached to the metal casing of the equipment during testing and the operation is convenient and convenient. Specification: Model ETCR1000C Functions Phase detection (Positive phase reverse phase and phaseloss) Live wire examination Simple Power detection Breakpoint location and Line maintenance. Power Supply DC 3V2xAA Alkaline dry battery Continuously working for 70 hours AC Voltage Range(V) AC 70 - 1000V 40/65Hz (Sine Wave Continuous Input) Clamp Wire Size External Diameter 1.6-16mm LED Display (Positive Phase Sequence) The four phase-sequence lamps light in order (clockwise). (Negative Phase Sequence) The four phase-sequence lamps light in order (counterclockwise). (Live Power)L1 L2 L3 lamp light up in the voltage setting range. (Phase Loss) L1 or L2 or L3 does not light. (Short Circuit)L1 or L2 or L3 does not light. Buzzing (Positive phase) The instrument emits intermittent short beeps; (Reverse phase) The instrument emits a continuous long beep. Power On Indication Power on indication light turns on; Low power low battery light on Magnetic force Four magnets on the back of the meter which are attached to the distribution box and can withstand 800g quality. Auto Power off After 5 minutes the meter automatically cut off power supply. Meter Dimension Width height thickness 70mmx75mmx30mm Clamp Length 0.6m Weight 317g Working Temperature and Humidity -10 degrees Celsius -55 degrees Celsius ; below
