NanoVNA-F Portable Handheld Vector Network Analyzer SWR Meter 50KHz-1000MHz 4.3 Inch IPS TFT Digital Display Touching Sc

NanoVNA F Handheld Vector Network Analyzer is a product based on the open source project of NanoVNA which is more professional and practical It includes a 4 3 inch IPS TFT IPLCD screen for clearer Features Use 4 3 inch IPS TFT LCD and resistive touch screen with a larger view angle and can be seen clearly in strong outdoor light The Lipo charing IC to be changed to IP5306 with 2A high charing current making the charging time shorter Use a larger and better operating level Use a larger and better operating power switch Support Chinese and English menu switching Upgrade the user program by virtual U disk 16MB SPI flash memory inside Standard aluminium housing to protect SMAhead and reduce the interference of external electromagnetic wave to instrument The NanoVNA F measurement range is 50k 1GHz Use the harmonic of the clock chip SI5351 to measure frequency up to 1000MHz At 600M 1GHz the S11 has a dynamic range of 40dB the standing wave ratio is less than 1 02 The RF front end is designed with a metal shield that allows the S21 to have a dynamic range better than 60dB over the full frequency range Specifications Main material PCBColor blackMeasurement frequency 50KHz 1000MHzRF output 13dBm Max 9dBm Frequency accuracy 0 5PPMPort SWR 1 1Display 4 3 inch IPS TFT 800 480 USB interface USB Type CCommunication mode CDC serial Power consumption USB 5V 200mA can use battery powered maximum charging current 2AOutput capacity 5V 1ANumber of calibration
