Multi-function Infrared Remote Control 8 Channel Relay Module Inching Switch/Self-lock Switch 5V/12V/24V Geekcreit for A

Features 1 Dual trigger design using a dedicated bidirectional driver IC design2 Strong anti interference ability using diode continuous current protection 3 The contact part of the relay adopts double sided thick wiring which can pass through a large current safe and reliable 4 Using high quality relays optional 5V 12V 24V 5 Both input and output adopt 5 08mm high quality wiring terminals making wiring more convenient and suitable for PLC control 6 The input terminal can be set arbitrarily high and low level trigger the control method is more flexible 7 Each relay has a pull in indicator light the working status of the relay is clear at a glance 8 Each relay output leads to two groups of normally open and normally closed electric shock which is convenient and flexible to use 9 With fixing screw holes for easy installation Specifications Working voltage 5V 12V 24V DCDimensions 133 x 55 x 19 mmContact capacity AC250V 10A DC30V 10A The product wiring is as follows 1 VCC input power supply terminal2 GND Input power terminal ground terminal3 CTR1 CTR8 is the signal input trigger terminal which is valid in any mode just set by jumper 4 Use of the remote control only the numeric keys work the 1 8 keys correspond to the corresponding 1 8 channels of the relay When pressed once the relay works and when pressed again the relay turns off When the 0 button is pressed all work is performed and when the 9 button is pressed all are disconnected Pa
