Multi-band NB-iot Wireless Communication Module with Huawei Chip WH-NB71 Embedded
HUAWEI
sku: 1474147
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$8.88
Shipping from: China
Description
Feature: Classification Parameter Value Wireless parameter Working frequency B1 B2 B3 B5 B8 B20 Transmit power Transmitting power: 23dBm~-40dBm Receiving sensitivity -115dBm Hardware paramete Data interface UART: 4800 bps, 9600 bps, 57600 bps, 115200bps Operating Voltage 3.1V~4.2V, recommended 3.8V Working current Maximum emission current in Active mode is 268mA@3V8 Receive current 64.5mA@3V8 in Active mode Idle current 4.3mA@3V8 PSM current 5A@3V8 (10A@3V8 in simple transparent transmission mode) Operating temperature -30C ~ +85C Extended temperature: -40 C ~ +85 C In the extended temperature, RF performance such as module transmit power may decrease, exceeding the 3GPP conformance requirements. Storage temperature -40C ~ +85C Working humidity 5%~95% RH (no condensation) Storage humidity 5%~95% RH (no condensation) Size Size: 17.5mm x 15.0mm x 2.4mm Package interface SMT surface sticker Package includes: 1 x Module
