Micsig RCP60XS/RCP300XS/RCP600XS/RCP1200XS/RCP3000XS/RCP6000XS Oscilloscope Probes Rogowski Current Probe 2Hz-30MHz Up t

Specifications Model RCP60XS RCP300XS RCP600XS RCP1200XS RCP3000XS RCP6000XSBandwidth 2 Hz 30 MHzRise Time ≤ 11 6 nsPeak Current Up to 6000 ApkOutput Sensitivity 100 mV A 10X to 1 mV A 1000X depending on the modelAccuracy Typical 2 Output Noise 5 mVpp Depending on the model Peak dI dt Up to 70 kA µsDroop ms Up to 2 msDelay Time Up to 20 nsEffect of Conductor Position Within ± 1 Offse Voltage ±1 mVPeak Coil Isolation Voltage AC 1 kVrms 1 min Measurable Conductor Diameter ≤ 20 mmPower Supply DC 12VIntegrator Size 70 40 17 mmWire Length Integrator to Rogowski Coil 1 5 mCoil Inner Diameter 25 mmCoil Circumference 80 mmCoil Cross Section Diameter Approx 1 6 mmInterface 1MΩ BNC Features High Bandwidth Performance Supports bandwidth from 2 Hz to 30 MHz ensuring precise measurement of high speed signals and rapid current changes Versatile Current Range Capable of measuring up to 6000 Apk perfect for capturing high current and high frequency signals Compact and Flexible Design Features a 1 6 mm thin flexible coil suitable for narrow pin spacing devices like TO 220 enhancing accessibility High Accuracy Provides 2 typical accuracy for precise measurement in semiconductor switching currents Wide Application Range Ideal for various applications including motor drives semiconductor power measurements and power conversion diagnostics Package Included 1 x Rogowski Current Probe Model as your choice 1 x Integrator1 x Power Supply
