Matek Mini Power Hub Power Distribution Board PDB With BEC 5V And 12V for RC Drone FPV Racing

Matek MiniPower HubPower Distribution Board With BEC 5V And 12V For FPV MulticopterThe Mini POWER HUB has been engineered to provide the highest possible performance and reliability in a 36 36mm4 layers PCB The HUB distributes power from a battery pack to 4 ESCs as well as providing two synchronisedregulated DC outputs for powering cameras servos video transmitters LEDs etc Batteries may range from 3S to 6S LiPo and the BEC input is TVS protected The HUB also features convenient solder bridge of various voltage for cameravideo transmitter Description Band name Matek Item name MatekPower Distribution Board Dimensions 36 x 36mm Weight About 6g Mounting holes 30 5mm square spacingFeatures 2oz copper4 layers PCB ESCBattery solder tabs in pairs Solder Bridges of various voltage for CameraVTX DC DC synchronous buck regulator Efficiency is up to 95 TVS Transient Voltage Suppressor protection for DC DC chip 5V12V Output LED indicatorsShort circuit tolerant Specification General Input voltage range 2S 6S operation 7 2 26VDC Regulated 5V and 12V outputs LED power indicators 5V12V outputs 4 ESC outputsESC outputs Continuous current 20A per output Peak current 10 seconds minute 30A per outputBEC 5V output Designed for RC Receivers Flight controllers OSD and Servos Voltage 5 0 0 1VDC Continuous current 3 Amps Short circuit tolerant 10 seconds minute LED indicates voltage is in regulation within 10 BE
