Mastech MS8268 AC DC Ohm Frequency Auto Range Digital Multimeter

sku: 910807

ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW

$39.12

Shipping from: China

Description

Description : Mastech MS8268 AC DC Ohm Frequency Auto Range Digital Multimeter Brand Name : MASTECH Model Number : MS8268 Measuring Voltage Range : 400 mV ~ 750 V Measuring Capacitance Range : 4 nF ~ 200 F Measuring Current Range : 400 A ~ 10 A Measuring Resistance Range : 400 ~ 40 M Operating Temperature : 0 ~ 40C (32 ~ 104 F) General Specifications : Display: 3 3/4 digits LCD with 4000 counts Sampling Rate: approx. 3 times / second Test Leads: 1KV 10A Safety Standards: IEC1010-1, CAT. III 600V & CAT. II 1000V Operating Temperature: 0 ~ 40C (32 ~ 104 F) Operating Humidity: below 80% RH, less than 10C non-condensing Storage Temperature: -10 ~ 60 C (14 ~ 140 F) Storage Humidity: below 80% RH Power: 3 x 1.5V AAA batteries (included) Dimensions: 195 mm x 92 mm x 55mm (7.68' x 3.62' x 2.17' inch) Weight: Approx.380g (including battery) (13.40oz) Electrical Specifications : Accuracy is (percentage of reading + number of digit) at (18 ~ 28) C, 0 ~ 75% RH. DC Voltage Range Accuracy Resolution 400 mV (0.7% + 2d) 0.1 mV 4 V 1 mV 40 V 10 mV 400 V 100 mV 1000 V (0.8% + 2d) 1 V Input impedance : 10 M Max. input voltage : 1000 V DC or 750 V AC rms AC Voltage Range Accuracy Resolution 400 mV (3.0% + 3d) 0.1 mV 4V (0.8% + 3d) 1 mV 40 V 10 mV 400 V 100 mV 750 V (1.0% + 3d) 1 V Input impedance : 10 M Frequency response : 4 V range : 40~200 Hz; other range : 40Hz ~ 1kHz Max. input voltage : 1000 V DC or 750 V AC rms Response : average, calibrated in rms of sine wave DC Current Range Accuracy Resolution 400 A (1.2% + 3d) 0.1 A 4000 A 1 A 40 mA 0.01mA 400 mA 0.1mA 10 A (2.0% + 5d) 10 mA Overload protection : 10A range : F 10A / 250V fuse, A and mA range : Resettable fuse(F400mA / 250V) Max input current : 10A range : 10A DC or 10A AC rms A and mA range : 400mA DC or 400mA AC rms AC Current Range Accuracy Resolution 400 A (1.5% + 5d) 0.1 A 4000 A 1 A 40 mA 0.01 mA 400 mA 0.1 mA 10 A (3% + 7d) 10 mA Overload protection : 10A range : F 10A / 250V fuse, A and mA range : Resettable fuse (400mA / 250V) Max input current : 10A range : 10A DC or 10A AC rms A and mA range : 400mA DC or 400mA AC rms Frequency range : 40Hz ~ 1kHz Frequency response : Average, calibrated in rms of sine wave Resistance Range Accuracy Resolution 400 (1.2% + 2d) 0.1 4 k 1 40 k 10 400 k 100 4 M 1 k 40 M (2.0% + 5d) 10 k Overload protection : 250V DC/AC rms Open circuit voltage : 250 mV Capacitance Range Accuracy Resolution 4 nF (5.0% + 5d) 1 pF 40 nF (3.0% + 3d) 10 pF 400 nF 100 pF 4 F 1 nF 40 F 10 nF 200 F 100 nF Overload protection : 250V DC/AC rms Frequency Range Accuracy Resolution 9.999 Hz (2.0% + 5d) 0.001 Hz 99.99 Hz 0.01 Hz 999.9 Hz 0.1 Hz 9.999 kHz 1 Hz 99.99 kHz 10 Hz 199.9 kHz 100 Hz >200 kHz Unspecified @ >200kHz 100 Hz Transistor Test Range Description Test Condition hFE Display read approx. hFE value(0 ~ 1000) of transistor under test (all type) Basic Current is Approx. 10 A. Vce is approx. 2.8V Overload protection : Resettable fuse (F400mA/250V) Diode Test Range Description Resolution Diode Display read Forward Voltage of Diode 1mV Forward DC Current : approx. 1mA Reversed DC Voltage : approx. 1.5V Overload protection : 250 V DC/ 150V AC rms Audible Continuity Range Continuity Beeper Buzzer less than 50 Open circuit voltage : approx. 0.5V Overload protection : 250V DC or 250V AC rms Package included : 1 x MASTECH MS8268 Digital Multimeter 2 x Test Lead 1 x Special Multifunction Socket 1 x User Manual 3 x 1.5 V AAA Batteries Details pictures :
