Mach3 Controller Wire Wireless Handwheel 4/6 Axis USB Controller Pulse Generator for CNC Engraving Machine

Description Mach3 Controller Kit Wired Wireless Handwheel 4 6 Axis USB Controller Pulse Generator for CNC Engraving Machine Specifications Handwheel ParametersType Wired Wireless HandwheelAxis 4 6 AxisWireless Transmission Parameters Communication ChannelISM 433MHZ Power Supply2x AA alkaline batteries NOT included Wireless Transmission Distancebarrier free 40meters Encoder100PPR Button16 support 10 macro code buttons Handwheel Performance Parameters Transmitting Power10DB Receiving Sensitivity 98DBDisplay128 68 Dot matrix LCD backlight displayMaterialABS PC Alloy Mach3 Motion Control Card ParametersModelMKX ETSize184 127 30mmAxis Output ControlDrive CurrentIsolated open collector output 5V 20mADrive Pulse direction outputOutput Frequency 2000KHZAxis Type4 axis MK4 ET6 axis MK6 ETIsolation Voltage3 5KVSpindle Inverter Output 3 types of output modes Analog Voltage Output 0 10VPWM Output5V 1KHZ Duty 0 100 Pulse Direction OutputMinimum output frequency 15HZMaximum output frequency 4KHZ8 IO OutputDrive CurrentIsolation 50mA 25VIsolation Voltage3 5KV16 IO OutputInput CurrentIsolated input 5mAMaximum voltage 25VIsolation Voltage3 5KVCommunication MethodEthernet InterfaceUSB InterfaceComplies with USB2 0 standard Features Handwheel 1 LCD Display Display the machine coordinate and workpiece coordinate of the X Y Z A axis Display spindle speed value machining feed speed value 2 Axis selection rate band switch control The axis selection band switch real
