MSO5104 Mixed Signal Oscilloscope 100 MHz Bandwidth 4 Analog Channels 16 Digital Channels 8 GSa/s Sample Rate 200 Mpts M

Specifications Analog Bandwidth Options 100 MHz default upgradable to 200 MHz 350 MHz or lower to 70 MHzSample Rate Up to 8 GSa s real time sample rateMemory Depth Supports up to 200 Mpts memory depth optional upgrade Channel Configuration 4 analog channels 16 digital channels requires additional LA probe Waveform Capture Rate Over 500 000 waveforms per second wfm s Display 9 inch WVGA capacitive touchscreen 1024 600 Trigger System Supports Zone Trigger with touchscreen interactionStorage and Playback Up to 450 000 frames for recording and playbackFeatures 1 Upgradable Bandwidth for Extensive Performance Needs The MSO5104 supports flexible bandwidth options starting at 100 MHz and upgradable to 350 MHz delivering unparalleled adaptability for varied testing applications 2 Deep Memory Depth for Seamless Testing Achieve reliable signal capture with up to 200 Mpts memory depth allowing greater precision during high speed analog and digital debugging 3 Advanced Multi Channel Analysis With 4 analog and 16 digital channels this oscilloscope enables synchronized testing across multiple signals for advanced circuit troubleshooting 4 High Speed Signal Acquisition Its 8 GSa s real time sampling rate and 500 000 wfm s waveform capture rate ensure rapid and accurate data visualization for dynamic signal environments 5 Intuitive Touchscreen Display The 9 inch WVGA capacitive touchscreen offers effortless gesture based operation and smooth user interaction ensuring e
