MS309 OBD2 Can Bus Engine Reader Car ATVFault Diagnostic Instrument OBD2 Clear Fault Code Diagnostic Scan Tool Universal

Specifications Product Name Car Fault DetectorDisplay 2 4 inchesVoltage 12VMain Control Chip MCUOperating Temperature 40 65 ℃ Supported Languages English German Dutch Spanish FrenchProduct Size 68 103 16mmWeight 165gFeatures 1 Retrieve generic and manufacturer specific diagnostic trouble codes DTCs including definition lookup software on CD and display DTC definitions on screen 2 Features a large easy to read backlit LCD screen multi language menus and DTC definitions and a standard 16 pin OBD II connector no additional cables required 3 View freeze frame data display monitor and I M ready status turn off the Check Engine Light MIL clear codes and reset monitors 4 Supports CAN Controller Area Network protocol and all other current OBD II protocols 5 For all OBD II compliant US European and Asian vehicles OBD II is standard on all cars sold in the US after 1996 Using the Scan Tool Procedure 1 Turn the ignition off 2 Locate the vehicle s 16 pin Data Link Connector DLC 3 Connect the scan tool cable connector to the vehicle s DLC The cable connector is keyed and can only be installed one way If you have trouble connecting the cable connector to the DLC rotate the connector 180 degrees and try again 4 Turn the ignition on Do not start the engine 5 When the scan tool cable connector is properly connected to the vehicle s DLC the LCD display will show instructions to select a new scan 6 Press the New Scan button and the display will
