MKS-GEN Controller Mainboard + TFT28 LCD Display + MOS Module Kit with 5Pcs drv4988 & Limit Switch for 3D Printer Ramps 1.4

Overview: About MKS-GEN Mainboard: 1, Assemble 2560 and ramps1.4 on a board to solve the problem of complex interface and easy failure of the Ramps1.4 interface. 2. Replaceable motor drive, support 4988 drive and 8825 drive, TMC2100 drive, s109 drive 3, Reserved external drive signal, can be connected to the external drive to drive 57, 86 motors. 4, The use of high-quality MOSFET tube, heat dissipation better, to ensure long-term stability. 5, The use of dedicated power chip, support 12V-24V power input, to solve the Ramps voltage conversion chip heating, inadequate power supply problem. 6, 24V input can be accepted. Under the same system power, the hotbed current can be reduced to 1/4, effectively solving the problem of heat pipe MOS heating. 7, The use of open source firmware Marlin, configuration and ramps1.4 exactly the same, can directly replace Ramps1.4. 8, Can be directly connected to the 2004LCD display and 12864LCD display, can support TFT28, TFT32 touch screen. 9. Reserve the motor pulse and direction output port to facilitate the external high current to be connected to a large current (such as 2A, 5A) motor drive circuit. 10. Retain the Servos, AUX-1, and AUX-2 interfaces on Ramps1.4, providing three 5V outputs and three 12V output interfaces. MKS-TFT28 display product features: - Interface customization: three sets of themes, a variety of styles - Strong compatibility: compatible with Marlin/Smoothieware/Repetier firmware, open source motherboard plug, and play - Accidental treatment: power failure continued, breakpoint continued, broken material detection, - Shutdown processing: Power off save, finish shutdown - Leveling processing: automatic leveling, manual leveling, leveling wizard - Network function: if the module, APP, - Cloud printing - Functional expansion: up to 13 custom instructions TFT28 display Parameters: 1. Appearance size: 93mm*80mm 2. Hole size: 88mm*65mm 3. Color touch screen: 2.8-inch touchscreen 4. Microprocessor: 32-bit STM32 processor 5. Support storage system SD card, U disk 6. Update method: SD file update 7. Support file format: Gcode 8. Extensible module (not included in delivery): WIFI module, shutdown module, break detection switch, power failure, external card slot About A4988 drive: 1, Suitable for driving the stepper motor below 8V-35V 2A. 2. Only a simple step direction control interface. 3, Fve different stepping modes: full, half, 1/4, 1/8 and 1/16. 4, The adjustable potentiometer can control the maximum current output, thus achieving a higher step rate. 5, Automatic current attenuation mode detection / selection. 6. Overheating shutdown circuit, under voltage lockout and cross current protection. 7, Grounding short circuit protection and load short circuit protection. About MOS MINI Module: 1. Excellent performance MOS tube (nominal maximum current 280A). 2, Iarge heat sink, the maximum current can be up to 30A. 3, You can directly use the hotbed output signal control of Ramp1.4 and MKS series motherboards. 4, Can use 5-24v digital signal control About Limit switch: - Light touch stroke limit switch - Product Description: normally open mechanical limit switch, compact size, easy installation, with trigger indicator. Plug and play. - Size: refer to the description picture Package Included: MKS GEN Motherboard * 1 USB cable * 1 MKS TFT28 display * 1 Limit switch * 6 MOS MINI Module * 1 80cm power cord * 2 A4988 drive * 5 Heat sink * 5
