MK S Gen V1.4 Control 3D Printer Mainboard Compatible RepRap Ramps1.4

Feature: 1. It gather 2560 and ramps1.4 on a same board, which solved the Ramps1.4 combination interface problem that easily out of order. 2. Can replace the motor driver, support 4988 drivers and 8825 drivers 3. Circuit board uses the high quality of 4 layer board,optimize heat dissipation;Ramp Is 2 layer board 4. Using special power supply chip, support the 12v-24v power input, solve the problem of Ramps voltage conversion of chip fever. 5. Accept 24V input, under the same system power can reduce the current hot bed to 1/4, effectively solve the problem of hot bed MOS tube heating 6. The firmware can use open source firmware Marlin, configuration are exactly the same with ramps1.4 , can be directly replace ramps1.4 also Can be connected directly to Ramps1.4, 2004 LCD control board and the LCD board (12864) 7. Provide three 5V output, three 12V-24V output interface. 4988 Driver Connection: Jumper plug is High, remove jumper to Low. Diagram: Note:If the power supply is wrong connection, motor driver board is likely to be burned chip and circuit, please confirm again after repeatedly for electricity.Package included:1 x MGK Gen V1.1 Motherboard1 x USB cable
