MDSO ISDS205A 2CH 20MHz 48MSa/s Virtual PC USB Oscilloscope FFT Analyzer Data Logger

Description: ISDS205A dual-channel digital oscilloscope, with "low-cost, high-performance" as the design goals. well-designed bandwidth of 20M, 48M sampling rate, 2 channels, alternating support X, Y and XY alternating pattern of two-channel virtual oscilloscope, spectrum analyzer, data recorder. The device communicate with the PC via high speed USB2.0. It is suitable for Xp, Win7(32) Win7(64) Win8(32) Win8(64) Win10(32) Win10(64) . Specification: Model Digital oscilloscope Spectrum analyzers Data recorder ISDS205A Digital oscilloscope Channels 2 Impedance 1M 25pF Coupling AC/DC Vertical resolution 8Bit Gain range -6V ~ 6V (probe X1) -60V ~ 60V (probe X10) Vertical accuracy 3% Timebase range 1ns-20s Input Protection Diode, 50Vpk Autoset Yes(10Hz to 20MHz) Trigger Mode Auto, Normal and Signal Trigger Type No, Rising edge, Falling edge, Rising edge or Falling edge Trigger level Yes Trigger Source CH1, CH2 Buffer Size 1MB/CH Bandwidth 20MHz Max sample 48MS/s Vertical mode CH1, CH2, ADD, SUB, MUL Display Mode X, Y-T & X-Y measurements Yes Wave save Osc(Private) Excel and Bmp Spectrum analyzers Channels 2 Bandwidth 20MHz Algorithm FFT(18 windows) correlation, power spectrum FFT points 8-1048576/CHN FFT measure Harmonic(1-7) SNR, SINAD, ENOB, THD, SFDR Filter processing FIR filter supports arbitrary range of frequency sampling method and Rectangle, bartlett, triangular, cosine, hanning, bartlett_hanning, hamming, blackman, blackman_Harris, tukey, Nuttall, FlatTop, Bohman, Parzen, Lanczos, kaiser, gaussand dolph_chebyshev, window method design. IIR filter support "Butterworth" "Chebyshev I" "Chebyshev II" "Elliptic" type of filter design Data recorder Channel 2 Impedance 1M 25pF Coupling AC/DC Vertical resolution 8Bit Gain range -6V ~ 6V (probe X1) -60V ~ 60V (probe X10) Sample 1 channel : 1K~24M Hz 2 channel : 1K~16M Hz Save File The maximum 4G, recording time associated with the sampling rate English User Manual Package includes: 1 x MDSO ISDS205A Oscilloscope 2 x Oscilloscope Probe 1 x USB cable 1 x BNC to Clip Cable 1 x CD (Manual etc.) Details pictures:
