MASTECH MS2115B True RMS Digital Clamp Meter Multimeter DC AC Voltage Current Ohm Capacitance Frequency Tester with USB
sku: 32655183010
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$81.21
Shipping from: China
Technical Details
| AC Current: | 60A/600A/1000A ±(2.5%+8) |
| AC Voltage: | 600mV/6V/60V/600V ±(0.8%+3) 750V ±(1.0%+4) |
| Brand Name: | MasTech |
| Dimensions: | 24.5*9.8*5.0cm |
| Display Type: | Digital Only |
| DIY Supplies: | Electrical |
| Duty Cycle: | 10%~90% |
| Frequency clamp: | 0~10KHZ ±(1.5%+5) |
| Frequency VAC: | 0~10KHZ ±(1.5%+5) |
| Inrush Current: | 60A/600A/1000A 60A for reference±(10%+60) |
| Logic Frequency: | 0~60MKHZ ±(0.5%+3) |
| Measuring Capacitance Range: | 6nF/60nF/600nF/6uF/60uF/600uF/6mF/60mF +/-(4.0%+3) |
| Measuring Current Range: | DC 60A/600A/1000A +/-(2.5%+8) |
| Measuring Inductance Range: | / |
| Measuring Resistance Range: | 600O/6KO/60KO/600KO/6MO +/-(1.0%+3) 60MO +/-(1.5%+3) |
| Measuring Voltage Range: | DC Voltage 600mV/6V/60V/600V+/-(0.5%+5) 1000V +/-(0.8%+4) |
| Model Number: | MS2115B |
| Operating Temperature: | 0~40 degrees |
| Weight: | 0.5kg |
