M5Stack Positive and Negative Air Pressure Sensor Module Programmable Development Gas Pressure Detection

Description Tube pressure is a wide range air pressure sensor that supports 100 200Kpa You can connect one end of the tube to the gas inlet This sensor transmitted onto mapping value 100 200Kpa and 0 1 3 1V voltage output Also having a protective housing for long term stability It s an accessory that your industrial use cannot live without Product Features Includes Integrated piezo resistive pressure sensor with wide temperature compensationLinear output easy to useMeasurement range 100 200KpaOutput 0 1 3 1VPrecision 1 5Kpa2x LEGAO compatible holesSupport UIFlow graphical programmingSpecification Sensor Model MCP H10 B200KPPNDetections GasMeasurement range 100 200KpaOutput 0 1 3 1VPrecision 1 5Kpa 0 85°C Supply voltage 5VNet weight 4 8gGross weight 10gProduct size 24 x 32 x 12mmPacking size 93 x 138mmPackage included 1 x Tube Pressure Unit1 x HY2 0 4P cableApplication Air pressure measurementOutput voltage and pressure value conversion P Actual test pressure value unit Kpa Vout sensor voltage output valueP Vout 0 1 3 0 300 0 100 0SchematicExamplesArduin0 include Arduin0 hint sensorPin 32 Sensor Pinvoid setup Serial begin 115200 pinMode sensorPin INPUT Sets the specified pin to input mode void loop float raw analogRead sensorPin read the value from the sensor float Vout raw 4095 3 6 float P Vout 0 1 3 0 300 0 100 0 Serial printf pressure f 2 Kparn P delay 100
