M5Stack Joystick Module MEGA328P I2C/Grove Connector Compatible X/Y Axis & Button Cap

Description JOYSTICK we have two types of JOYSTICKs one is build 0n a panle compatible with FACES Kit this is the M5Unit version of JOYSTICKJOYSTICK is very similar to the analog joystick on PS2 Play Stati0n 2 controllers The X and Y axes are two 10k potentiometers which control 2D movement by generating analog signals The joystick also has a push button that could be used for special applications Therefore the entire Unit can output X Y motion signals in both directions and Z direction As designed in the schematic the Joystick X dimension is connected to pin A0 of MEGA328 the Joystick Y dimension is connected to pin A1 on MEGA328 the Joystick Z dimension is connected to pin A2 on MEGA328 This Unit communicates with the M5Core via the GROVE A interface It s I2C address is 0x52 By reading the data transferred from JOSTICK you can obtain the motion information of JOYSTICK Product Features Output value of X Y direction 10 250Output value of Z direction is 0 released 1 pressed Software Development Platform for UIFlow Blockly Python Two LeIgo compatible holesProduct Size 48 2mm x 24 2mm x 22 5mmProduct weight 11 4gPackage Included 1x JOYSTICK Unit1x Grove CableApplication Game ControllerRobot remote controlRelated Link Offical VideoForumPinMap Mega328 ISPDownload interface Pin foot definitionExample1 forIDEThe code below is incomplete just for usage To get complete code please click here 2 UIFlowTo get complete code please click here Schematic P
