M5Stack Digital Electronic Scale Kit 24-bit A/D Converter Chip HX711 Built-in Programmable IoT Weighing Scale Kit

M5Stack Digital Electronic Scale Kit 24-bit A/D Converter Chip HX711 Built-in Programmable IoT Weighing Scale Kit
M5Stack
артикул: 1938279
СОГЛАСНО НАШИМ ДАННЫМ, ЭТОТ ПРОДУКТ СЕЙЧАС НЕ ДОСТУПЕН
$19.43
Доставка из: Китай
   Описание
Description Scales Kit is a high precision low cost weighing kit This digital Scales kit is consist of four pieces of half bridge resistive strain gauges with a total weighing range of 200kgs It is equipped with a 24 bit A D converter chip HX711 specially designed for the high precision electronic scale The built in low noise programmable amplifier supports 32 64 128 times gain adjustment With the help of M5Stack core for programming you can create IoT based Weighing Scale in just a few minutes NOTE The Scale Kit will need a cover plate to work with and the size of the cover plate should not exceed 50cm on one side Product Features Total weighing range of 200kgsHX711 High precision 24bit ADCProgrammable gain amplification 32 64 and 12810SPS output data rateHalf bridge resistive strain gauge Output sensitivity 1 0±0 1mV VNon linearity 0 3 F SIntegrated Accuracy 0 3 F SZero output ±0 3mv VDifference between upper and lower impedance of each strain gauge 0 8ΩOutput in impedance 1000±5ΩDevelopment platform UIFlow To be supported soon Arduin0Specification SpecificationsParametersHX711Output Sensitivity High Precision 24bit ADCProgrammable Gain Amplification 32 64 12810SPS Output Data RateHalf Bridge Resistance Strain GaugeOutput Sensitivity 1 0±0 1mV VNonlinearity 0 3 FSComprehensive Accuracy 0 3 FSZero Output ±0 3mv VEach The difference between the upper and lower impedance of the gauge strain gauge 0 8ΩOutput input impedance 1000±5ΩGross Weight92 5
